Specifications:

• Part OEM: Bendix 800257
• Part: MV-3 Manifold Dash Valve
• Mounting Holes: Unthreaded
• Trailer Delivery: 3/8" Push-To-Connect
• Reservoirs: 3/8" Push-To-Connect
• Exhaust(2): 3/8" Push-To-Connect
• Tractor Delivery: 3/8" Push-To-Connect
• Auxiliary Supply: 3/8" Push-To-Connect
• Tractor Valve: 20 - 35 PSI
• Trailer Valve: 20 - 45 PSI
• Non-Override: 25 ± 5 PSI
• Material: Heavy Duty Polymer (EGC-Engineering Grade Composite)

• Notes: Yellow Knob (Parking Brake) and Red Knob (Trailer Air Supply) are Included. All Ports 3/8" Push-To-Connect Fittings

CrossReference:

• Automann: 170.800257WF
• Bendix: 800257
• Mack: 745-800257
• Navistar-International: 2014785C93, 3592131C91
• Newstar: S-16929
